Rigid steel frame construction
Electromechanical drive system
Programmable digital interface
Real time monitoring
Safety enclosure with emergency stop
Data export options
Compatible molds
Selectable end conditions
Applied Pressure 600kpa ± 60kpa (0 – 5 gyrations) & ± 18kpa (above 5 gyrations)
Internal Angle of Gyration 1.16° ± 0.02°
Speed of Gyration 30 ± 0.5 RPM
Number of Gyrations 0 -600
Specimen Sizes 100 mm & 150 mm
Product Dimension 750 (W) x 915 (D) x 1400 (H) mm
Approx. Weight 386 kg
Power 220~240 VAC, 1 Ph, 50/60 Hz, 10 A
